M - Y Values
P X T = Max. Pressure (psi) X Max. Temperature (F)
350,000 (1/32" & 1/16") 250,000 (1/8")
Temperature Limits -350F to 500+F
Pressure Limits @ Max. Temp = 1200 psi, 800 psi for E-140 only
Pressure limits @ Max. Temp = 1400 psi for E-900
The M and Y Values for E-110, E-600, E-900, E-140, and E-250
|
M |
Y |
M |
Y |
1/32" |
3.75 |
7600 |
3.5 |
6500 |
1/16" |
3.00 |
4500 |
2.70 |
3500 |
3/32" |
2.50 |
2900 |
2.25 |
2200 |
1/8" |
2.25 |
2200 |
2.00 |
1600 |
The data set forth in this presentation is typical. The users specific application should be combined with independent study and evaluation for the mateerials suitibility. E-600 Fluorogreen, E-110 Fluorogreen, E-140 Fluoroblue, E-250 Fluoromaroon are registered trademarks of United Fluoro Components. All Fluorogreen products are made in the U.S.A.
E-110 and E-600 |
E-900, E-140, and E-250 |
